Advanced sweeping technology to ensure the accuracy of PLT.
HD color display, sensitive touch, support rubber gloves operation.
SMART-FLOW liquid circuit invention patent technology.
CBC+DIFF mode. ≤20 microliter.
Specifications
Measurement speed/volume of blood used
60 samples/hour
CBC+DIFF mode: ≤20 µl
Use environment
Wide range input: a.c. 100-240V,50/60Hz
Temperature: 10-30°C
Humidity: 20-85﹪
Atmospheric pressure: 70-106KPa
Altitude: ≤2000m
Measurement technology
Semiconductor laser scattering technology
Flow cytometry
Three-dimensional scatter plot analysis technology
Electrical impedance measurement technology
Cyanide-free HGB measurement technology
Storage capacity
More than 100,000 copies stored
(including histogram, scatter plot, patient information)
LCD touch screen
14 inches
Resolution 1366*768
Measurement mode
CBC+DIFF mode
Venous whole blood mode, pre-diluted peripheral blood mode, and
Anticoagulated peripheral whole blood mode
Expansion interface
1 network port, 4 U
Two-way LIS system supports HL7 protocol
External USB printer or WIFI connection (optional)
Built-in RFID reader scanning (optional)
Size/Weight
WXHXD.
350mmX450mmX430mm
Approx. 28kg
Measurement items
Reported parameters (25 items)
WBC, RBC, HGB, HCT, MCV, MCH, MCHC,RDW-SD, RDW-CV, PLT, MPV, PCT, PDW,P-LCR, P-LCC, NEU%, LYM%, MON%, EOS%,BAS%, NEU#, LYM#, MON#, EOS#, BAS#
Study parameters (4 items):
ALY%, ALY#, LIC%, LIC#
Two scatter plots, one 3D scatter plot (as needed)
call up 2 2D plots, one WBC/BASO scatter plot, the 2 histograms (RBC histogram, PLT histogram)
