Features

Intelligent operating system upgrade capable of handling a variety of complex analyses, including timed measurements, parameter settings, and data locking, applicable for multiple parameters such as pH, conductivity, and dissolved oxygen.

3.5’’TFT Color Display, easy to read

The new UI interface, easy operation

Intelligent function with Auto. timing datalogger, parameter setting, data holder

Data storage up to 3000 groups

Cond mode: Support probe constant calibration, conductivity standard solution calibration

Power supply: rechargeable lithium battery/USB

Charging socket: USB/Type-C, in line with the European new regulations.

Protection class: IP57

Parameters

Parameter Cond/TDS/Sal./Res.℃ | DO.℃

pH Resolution -

pH Calibration points -

ORP Measurement range -

pH Measurement range -

pH Accuracy -

pH ATC range -

ORP Resolution -

ORP Accuracy -

Conductivity Measurement range 0~2000.0mS/cm,auto-ranging:0~19.999μS/cm;

20.0~199.9μS/cm;200~1999μS/cm;

2.00~19.99mS/cm;20.00~199.9mS/cm;

200.0~2000mS/cm(K=10);Match test range:0~200mS/cm;

TDS:0~100.0g/L(TDS factor adjustable)

Resistivity:5.000Ω·cm~100.0MΩ·cm;Salinity:0~100ppt

Conductivity Calibration points one point

Conductivity ATC range (0.0~50.0) ℃/(32.0~122.0)°F

DO Measurement range (0.00~20.00)mg/L

Conductivity Resolution 0.001/0.01/0.1/1

Conductivity Accuracy ±0.5% FS ±one digit

DO Accuracy ±0.30mg/L

DO saturation (0.0~200.0)%

DO Automatic barometric pressure compensation (0~200.0)kPa

DO Automatic temperature compensation (0.0~50.0) ℃/(32.0~122.0)°F

Temperature Measurement range (0.0~100.0) ℃/(32.0~212.0)°F

Charging socket Type-C

DO Manual salinity compensation 0~45ppt

Temperature Accuracy Rechargeable lithium battery

Power supply Rechargeable lithium battery

IP Rating IP57

Test kit Meter;Plastic ATC Cond probe DCON201T,K=1.0;

Polarographic DO probe DDO01-2M-H,cable length:2m;

Standard Cond solution:

84μS/1413μS/12.88mS/cm,50mL,one for each;

Membrane refill solution:DDOS-01,30mL,1btl;

Membrane sensor caps DDOSC:3pcs/group,1pkg;

Rechargeable lithium battery(pre-installed);

Charging cable:1pc;

Hard carrying case(L/W/H:33.0x27.8x8.2cm):1pc
