Main Fame
Working Mode: For the Closed System, Semi-Closed System and Semi-Open System
Application: Adult and Children
Alarms Parameters: Upper and Lower Airway Pressure Alarm: Upper and Lower Tidal Volume Alarm; Lack of Oxygen Alarm; Apnea; Power Outages
Airway Pressure: O2:0.3MPa--0.5MPa, N2O: 0.3MPa--0.5MPa
Power: 220V±10%,50Hz±1%
Oxygen Flush: 35L/min--75L/min
Anesthesia Ventilator
Two Bellows: Adult and Children
Monitoring Parameters: Tidal Volume, the Respiratory Rate; I/E Ratio; the Peak Airway Pressure; Airway
Respiratory Modes: IPPV, SIGH, SIMVIF/2, PEEP (+.5kRa--+2kPa), SIPPV
Respiratory Rate: 4 -- 60bpm
Tidal Volume: 30 -- 1500ml
I/E Ratio: 3; 1 -- 1:4 Adjustable
Pacakge Size:
one wooden box:84*63*73cm,
gross weight:70KG
another wooden box: 84*83*96cm,
gross weight: 110KG
