1.Microprocessor control, operated by touch panel, visual digital display, operated data can be saved automatically, RCF value can be set directly for working, easy to use.
2.Brushless motor, imported super speed bearing from Europe, smooth running and maintenance free.
3.Steel body, stainless steel centrifugal chamber, multistage damping system, low noise and slight vibration, green.
4.With rotor identification, overspeed, door interlock, imbalance protections, the rotor can be high temperature & high pressure sterilization, ensure safety.
5.Special air current design, the temperature of centrifuge chamber is stable. can effectively protect the samples.
6.Adjustable acceleration and deceleration from grade 0 to 9 or directly set the time of Accel/Decel, 40 kinds of self-defining operating programs can be stored and recall, to achieve the best centrifugal result.
7.Hold-on and transient centrifuging, easy to diverse centrifugation.
technical parameter
|
Model
|
YSCF-TD5Z
|
|
Max Speed
|
5000r/min
|
|
Max Rcf
|
4390×g
|
|
Max Capacity
|
800ml
|
|
Speed Accuracy
|
±20r/min
|
|
Time Range
|
0-999min/sec
|
|
Power Supply
|
AC 220V 50Hz 10A
|
|
Noise
|
≤60dB
|
|
Dimension
|
550×400×370mm
|
|
Weight
|
40kg
|
|
Model
|
Number
|
Capacity
|
Max Speed (r/min)
|
Max RCF(×g)
|
Dimension of tube
|
|
Swing Rotor
|
No.63
|
4×50/100ml
|
5000
|
4390
|
Φ38×124
|
|
No.77
|
32/24×5ml
|
4000
|
2810
|
Φ16×85-118
|
|
No.78
|
16×10/15ml
|
4000
|
2810
|
Φ16×85-118
|
|
No.81
|
8×50/100ml
|
4000
|
2810
|
Φ28×105-115
|
|
No.82
|
4×50ml
|
4000
|
2810
|
50ml Syringe
|
|
Microtiter Plate Rotor
|
No.43
|
2×2×96
|
4000
|
2300
|
Microtiter Plate Rotor
|
|
No.44
|
2×48
|
4000
|
2300
|
