1.Microprocessor control, operated by touch panel, visual digital display, operated data can be saved automatically, RCF value can be set directly for working, easy to use.
2.Brushless converter motor which has high torque, Imported super speed bearing from Europe, smooth running and maintenance free.
3.Steel body, multistage damping system, low noise and slight vibration, green.
4.The freon-free compressor from Europe, stainless steel centrifugal chamber, fast cooling, pre-cooling design makes high working efficiency.
5.Equipped with identification system, overspeed, over temperature, door interlock, imbalance protection function, ensure operation safety. The rotor can be high temperature & high pressure sterilization
6.Can be configured 5ml, 7ml, 10ml, 15ml, 30ml,50ml and several kinds of adapters, to meet the customer's multiple needs.
7.Adjustable acceleration and deceleration from grade 0 to 9 or directly set the time of Accel/Decel, 40 kinds of self-defining operating programs can be stored and recall, to achieve the best centrifugal result.
8.Hold-on and transient centrifuging, easy to diverse centrifugation.
TECHNICAL PARAMETER
| Model |
YSCF-TDL5M |
| Max Speed |
5000r/min |
| Max RCF |
4390×g |
| Max Capacity |
1000ml |
| Speed Accuracy |
±20r/min |
| Temperature Range |
-20ºC-+40ºC |
| Temperature Accuracy |
±1ºC |
| Time Range |
0-999min/sec |
| Power Supply |
AC 220V 50Hz 18A |
| Noise |
≤60dB |
| Dimension |
640mm×680mm×380mm |
| Weight |
95kg |
Rotor
| Model |
Number |
Capacity |
Max Speed (r/min) |
Max RCF(×g) |
Dimension of tube |
| Swing Rotor |
No.63 |
4×50/100ml |
5000 |
4390 |
Φ38×124 |
| No.70 |
4×250/8×50/32×10ml |
4000 |
3500 |
Φ64×113 |
| No.77 |
32/24×5ml |
4000 |
2810 |
Φ13×75-118 |
| No.78 |
16/12×10/15ml |
4000 |
2810 |
Φ16×85-118 |
| No.81 |
8/6×50/100ml |
4000 |
2810 |
Φ28×105-115 |
| No.82 |
40/48×5ml |
4000 |
2800 |
Φ14×54 |
| No.85 |
96×5/7ml |
4000 |
2800 |
Vacumm Blood Collection Tube |
| No.85 |
80×5/7ml |
4000 |
2800 |
Vacumm Blood Collection Tube |
