FEATURES:
1. Microprocessor control, operated by touch panel, LED display, operated data can be saved automatically, RCF value can be set directly for working, easy to use.
2. Brushless converter motor which has high torque, High speed bearing from Europe, smoothly running and maintenance-free.
3. Multistage damping system, low noise and slight vibration,green.
4. Steel body, stainless steel centrifugal chamber, imports of key components, durable and easy to clean.
5. Overspeed, door interlock, imbalance protection. The rotor can be disinfected at high temperature & high pressure, ensure safety.
6. Proprietary air current design, small temperature-rise of centrifuge chamber, effective protection of the sample.
7. Adjustable acceleration and deceleration from grade 0 to 9, 40 kinds of self-defining operating programs can be stored and recall, achieving the best centrifugal result.
8. Hold-on and transient centrifuging, easy to diverse centrifugation
TECHNICAL PARAMETER:
Model |
TG16B |
Max Speed |
16000r/min |
Max RCF |
17800×g |
Max Capacity |
40ml |
Speed Accuracy |
±20r/min |
Time Range |
0-99min |
Power Supply |
AC 220V 50Hz/110V 60Hz, 8A |
Noise |
≤60dB |
Dimension |
280×380×230(mm) |
Net Weight |
14kg |
ROTOR OPTIONS:
Rotor Type |
No. |
Capacity (ml) |
Max Speed (r/min) |
Max RCF (×g) |
Dimension of tube (mm) |
Angle Rotor |
21 |
18×0.5ml |
16000 |
17800 |
Φ8x32 |
19 |
12×1.5/2.0ml |
16000 |
17800 |
Φ10x42 |
|
23 |
8×5ml |
13000 |
10000 |
Φ14x54 |
|
Capillary Tube rotor |
25 |
24×(0.25~1)ml |
12000 |
14800 |
capillary tube |
